Features
- Three-phase 500VAC 150A
Low-profile
High-attenuation from 150kHz to 1MHz
2-stage filter - Maximum input voltage 528VAC: 10% fluctuations in voltage 480VAC
Selectable leakage current value - Alternative Energy, Factory Automation
Part Number Configuration
TBC(1) - 150(2) - 683(3)
(1) Model Name(2) Rated Current
(3) Line to ground capacitor code
Refer to Product Line-up.
* When the line to ground capacitor code is different, the attenuation characteristic is
different.
