PMM15-48S
Options
Drawings
Safety Certificates
Powerbox is recognized for technical innovations that reduce energy consumption and its ability to manage full product lifecycles while minimizing environmental impact. Powerbox is a Cosel Group Company.
| Basic Specification | PMM15-48S05 | PMM15-48S12 | PMM15-48S15 | PMM15-48S24 | PMM15-48S05W | PMM15-48S12W | PMM15-48S15W | PMM15-48S24W |
|---|---|---|---|---|---|---|---|---|
| Check Stock | Check Stock | Check Stock | Check Stock | Check Stock | Check Stock | Check Stock | Check Stock | |
| Input Voltage Range | DC36 - 75V | DC36 - 75V | DC36 - 75V, DC18 - 75V | DC36 - 75V, DC18 - 75V | ||||
| Output Voltage / Current | 5V 3A | 12V 1.25A | 15V 1A | 24V 0.625A | 5V 3A | 12V 1.25A | 15V 1A | 24V 0.625A |
| Output Power | 15W | 15W | 15W | |||||
| Output Voltage Adj Range | Refer to datasheet | Refer to datasheet | Refer to datasheet | |||||
| Operating Temp (°C) | -40 to 105℃ | -40 to 105℃ | -40 to 105℃ | |||||
| Cooling Method | Convection | Convection | Convection | |||||
| Dimensions (W x H x D) | 25.4x10.2x40.6mm | 25.4x10.2x40.6mm | 25.4x10.2x40.6mm | |||||
| Safety Agency Approvals | ||||||||
| Technical Data | PMM15-48S05 | PMM15-48S12 | PMM15-48S15 | PMM15-48S24 | PMM15-48S05W | PMM15-48S12W | PMM15-48S15W | PMM15-48S24W |
| Performance Data | On request | On request | On request | On request | On request | On request | On request | On request |
| EMC Data | On request | On request | On request | On request | On request | On request | On request | On request |
| Expected Life | N/A | N/A | N/A | N/A | N/A | N/A | N/A | N/A |
| MTBF | On request | On request | On request | On request | On request | On request | On request | On request |
| Reliability Data | ||||||||
