PRODUCTS AC-DC PDA SERIES PDA600F

PDA600F

Basic Function AC-DC Power Supply
Cost Effective
5 Year Warranty
EN & UL Approved

(For detailed information, please refer to the instruction manual)

PD⁽¹⁾　A⁽²⁾　600⁽³⁾　F⁽⁴⁾　-　□⁽⁵⁾

(1) Series name
(2) Single output
(3) Output wattage
(4) Universal input
(5) Output voltage

string(240) "PD⁽¹⁾　A⁽²⁾　600⁽³⁾　F⁽⁴⁾　-　□⁽⁵⁾
(1) Series name
(2) Single output
(3) Output wattage
(4) Universal input
(5) Output voltage"

PD⁽¹⁾　A⁽²⁾　600⁽³⁾　F⁽⁴⁾　-　□⁽⁵⁾

(1) Series name
(2) Single output
(3) Output wattage
(4) Universal input
(5) Output voltage

Basic Specification	PDA600F-12	PDA600F-15	PDA600F-24	PDA600F-36	PDA600F-48
	Check Stock	Check Stock	Check Stock	Check Stock	Check Stock
Input Voltage Range	85 - 264VAC 1Φ			85 - 264VAC 1Φ
Output Voltage / Current	12V 53A	15V 43A	24V 27A ACIN 100V 24V 27 (31) A ACIN 230V	36V 18A	48V 13A
Output Power	636W	645W	648W		624W
Output Voltage Adj Range	8.25 - 13.20V	10.50 - 16.50V	16.50 - 26.40V	25.20 - 39.60V	38.40 - 56.00V
Operating Temp (°C)	-20 to +70℃ (Required Derating), 20 - 90%RH (Non condensing)			-20 to +70℃ (Required Derating), 20 - 90%RH (Non condensing)
Cooling Method	Forced cooling (internal fan)			Forced cooling (internal fan)
Dimensions (W x H x D)	120x61x190mm (without terminal block and screw)			120x61x190mm (without terminal block and screw)
Safety Agency Approvals	UL62368-1, C-UL (CSA62368-1), EN62368-1, Complies with DEN-AN			UL62368-1, C-UL (CSA62368-1), EN62368-1, Complies with DEN-AN
Technical Data	PDA600F-12	PDA600F-15	PDA600F-24	PDA600F-36	PDA600F-48
Performance Data
EMC Data
Expected Life
MTBF
Reliability Data
