OBJ55-2

NRND

Options

(For detailed information, please refer to the instruction manual)

string(0) ""

Product Data

  • Datasheet
  • Instruction Manual
  • Glossary of Technical Terms

Drawings

Safety Certificates

  • Reach declaration
  • Certificate TÜV
  • DoC declaration
  • RoHS declaration

Powerbox is recognized for technical innovations that reduce energy consumption and its ability to manage full product lifecycles while minimizing environmental impact. Powerbox is a Cosel Group Company.

Basic Specification OBJ07204A OBJ07210A OBJ07204C OBJ07210C
  Check Stock Check Stock Check Stock Check Stock
Input Voltage Range AC110 - 230V AC110 - 230V
Output Voltage / Current V1: 5V 8A
V2: 12V 3A
V1: 5V 8A
V2: 24V 1.5A
V1: 5V 8A
V2: 12V 3A
V1: 5V 8A
V2: 24V 1.5A
Output Power 55W 55W
Output Voltage Adj Range Refer to datasheet Refer to datasheet
Operating Temp (°C) -10 to 50℃ -10 to 50℃
Cooling Method Convection Convection
Dimensions (W x H x D) 73.1x33.6x117.2mm 73.1x33.6x117.2mm
Safety Agency Approvals
Technical Data OBJ07204A OBJ07210A OBJ07204C OBJ07210C
Performance Data On request On request On request On request
EMC Data On request On request On request On request
Expected Life N/A N/A N/A N/A
MTBF On request On request On request On request
Reliability Data
