KHEA480F
Options
KH□(1) A(2) 480(3) F(4) - □□(5) - □(6)
(1) Series name
KHE: Euro style I/O terminals
KHN: Barrier blocks style I/O terminals
(2) Single output
(3) Output wattage
(4) Universal input
(5) Output voltage
(6) Option
C: with Coating
N2: Screw mounting
3D product images are available.
Read Me First
Standard model
| Basic Specification | KHEA480F-24 | KHEA480F-48 |
|---|---|---|
| Check Stock | Check Stock | |
| Input Voltage Range | AC85 - 264V 1Φ or DC88 - 350V | |
| Output Voltage / Current | 24V 20A | 48V 10A |
| Output Power | 480W | |
| Output Voltage Adj Range | 22.5 - 26.4V | 45.0 - 55.2V |
| Operating Temp (°C) | -25 to +70℃, 20 - 90%RH（Non condensing）, Type tested for -40℃ start-up（Required to Derating） | |
| Cooling Method | Convection | |
| Dimensions (W x H x D) | 70x124x117mm | |
| Safety Agency Approvals | ||
| Technical Data | KHEA480F-24 | KHEA480F-48 |
| Performance Data | ||
| EMC Data | ||
| Expected Life | ||
| MTBF | ||
| Reliability Data | ||
