KHEA240F
Options
KH□(1) A(2) - 240(3) F(4) - 24(5) - □(6)
(1) Series nameKHE: Euro style I/O terminals
KHN: Barrier blocks style I/O terminals
(2) Single output
(3) Output wattage
(4) Universal input
(5) Output voltage
(6) Option
C: with Coating
N2: Screw mounting
3D product images are available.
Read Me First
Standard model
| Basic Specification | KHEA240F-24 |
|---|---|
| Check Stock | |
| Input Voltage Range | AC85 - 264V 1Φ or DC88 - 370V |
| Output Voltage / Current | 24V 10A |
| Output Power | 240W |
| Output Voltage Adj Range | 22.5 - 28.5V |
| Operating Temp (°C) | -25 to +70℃, 20 - 90%RH（Non condensing）, Type tested for -40℃ start-up（Required to Derating） |
| Cooling Method | Convection |
| Dimensions (W x H x D) | 50x124x117mm |
| Safety Agency Approvals |
|
| Technical Data | KHEA240F-24 |
| Performance Data | |
| EMC Data | |
| Expected Life | |
| MTBF | |
| Reliability Data |
